API Interface Landscape Diagram

End-to-end API and interface view showing frontend access to secured CMS backend services, internal domain and platform APIs, storage access interfaces, identity endpoints, outbound delivery interfaces, and observability ingestion

🔌

Frontend, Services, and External Interfaces

FRONTEND-FACING API INTERFACES

React SPA

Frontend consumer of controlled CMS APIs for all user-visible screens and actions

API

CMS Backend APIs

Primary frontend-facing secured APIs exposed by CMS backend services for UI screens, workflows, and operational actions

REST / JSON Contract

Main application contract between browser and secured CMS backend services

Authenticated API Calls

Requests are sent with token-backed identity context rather than anonymous access

The React frontend accesses secured CMS backend APIs, which route requests to the appropriate domain and platform services.

INTERNAL APPLICATION API LANDSCAPE

Internal service interfaces used by protected backend flows across domain and platform services

PRO

Profile API

Profile and contextual user data

ROS

Roster API

Roster and schedule interfaces

ATT

Attendance API

Attendance and status interfaces

EVT

Events API

Event-related service interface

PRD

Productivity API

Operational KPI and productivity access

Workflow API

Submission, transition, tracking, and status endpoints

Notification API

Internal notification reads, state updates, and trigger interfaces

DOC

Document API

Upload, metadata lookup, and secure retrieval interfaces

SRV

Internal Service Contracts

Protected service-to-service interfaces between CMS domain and platform services

Internal services reach data systems and external interfaces only through backend-managed access interfaces, not through direct browser calls.

DATA ACCESS INTERFACES

Fabric Access Interface

Read-only backend data-access interface for curated enterprise analytical datasets

DocumentDB Access Interface

Operational read / write interface for workflow state, notifications, preferences, and metadata

ADLS Access Interface

Backend-controlled upload / download and file object access interface for document content

IDENTITY & SECURITY INTERFACES

Azure AD Auth Endpoints

SSO, token issuance, and identity validation interfaces

JWT

Token Validation Interface

Protected APIs validate bearer tokens before serving business requests

RBAC

Backend Authorization Enforcement

RBAC and ABAC are enforced directly within CMS backend services for protected APIs, workflows, and document access

SEC

Protected Interface Boundary

The browser is outside the trust boundary; protected interfaces are enforced server-side

EXTERNAL INTEGRATION INTERFACES

Infobip API

Outbound delivery interface used by notification flows for asynchronous message dispatch

Datadog Ingestion Interface

Logs, traces, metrics, and observability signals are exported to Datadog

MON

Monitoring & Alerting Interfaces

Operational telemetry, alerting, and trace visibility are handled through centralized observability integrations

INTERFACE LANDSCAPE PRINCIPLES

UI Uses Secured Backend APIs

The browser consumes secured CMS backend APIs rather than directly accessing internal services or enterprise data platforms

Services Keep Clear Boundaries

Internal APIs stay separated by domain and shared-platform responsibilities

Data Access Is Mediated

Storage and analytics platforms are reached through backend interfaces, not direct client access

External Calls Stay Downstream

Delivery and observability integrations are downstream of protected backend business decisions

          Frontend-facing interfaces
          Internal application APIs
          Data access interfaces
          Identity & security interfaces
          External integration interfaces
          Landscape principles
